3.1 M3A-HS86 Connectors Outline

Rev.1.0 Feb 6, 2007

3-2

REJ10J0916-0100

3

3.1 M3A-HS86 Connectors Outline

Figure3.1.1 shows M3A-HS86 connector assignments.

J3
Serial Port
Connector

J5
Power Supply Connector

J1
H-UDI Connector
(36-pin)

J2
H-UDI Connector
(14-pin)

J14
Extension Connector

J7,J8
User I/O Connector

J4
External Power
Supply Connector

< Top View of the Solder Side >

J13
Extension Connector

J11
Extension Connector

J12
Extension Connector

J6
User I/O Connector

J10
Extension Connector

J9
Extension Connector

Figure3.1.1 M3A-HS86 Connector Assignments
