Figure 4-1. CL-810 OSD Menu Structure
Option
Reset Image Settings Yes / No
Sleep Timer 0, 10, 20, 30 ... 180 minutes
Lamp Hours (read only)
OSD Timer 0, 3, 6, 9 ... 60 seconds
OSD Position
Horizontal
Vertical
PC & HD Adjust (480p
and higher-res. signals
only)
Auto
Frequency 0, +1, +2, +3 ... +17
Phase 0, +1, +2, +3 ... +31
H. Position -30, -29 ... 0 ... +29, +30
V. Position -28, -27 ... 0 ... +29, +30
PIP/PBP Set Up
(not available when used
with the SDC-1)
PIP/PBP Enable On / Off
PIP Set Up
PIP Off
Graphic in Video
Video in Graphic
PBP Set Up
PBP Off
Graphic by Video
Video by Graphic
DNR 0, +1, +2, +3 ... +15
Set Up
White Balance
Gamma
Red / Green / Blue Gain
Offset
Store Color Temp. 4
Store Color Temp. 5
Gamma Selection
2.8, 2.5, 2.2, 1.0,
RUNCO Enhance 1,
RUNCO Enhance 2 or ISF
Day
SD Enhance
H Enhance
0, +1, +2, +3 ... +127
V Enhance
Chroma Enhance
H Threshold
V Threshold
Chroma Threshold
RVR Adjust 0, 1, 2 ... 19
Image Over Scan
Total 0, +1, +2, +3 ... +15
Horizontal
Vertical
Image Shift
Horizontal
-30, -29, ... 0 ... +29, +30
Vertical
Amplitude Adjust
Horizontal
-60, -59 ... 0 ... +59, +60
Vertical
Horizontal Masking 0, +1, +2, +3 ... +100 (CineWide versions only)
Video Black Level 0 IRE or 7.5 IRE
Lamp Power 250W or 200W
Remote Control
Primary
Secondary
Reset Lamp Timer Yes / No
Fan Control
Mode
Auto Normal,
Auto Hi. Altitude or Manual
Fan Speed (Manual Mode)
Screen Trigger Mode Normal or AutoScope (CineWide versions only)
Return to User OSD
ISF
Calibration
Reset Picture Adjust Yes / No
Picture Adjust
Brightness, Contrast, Color
etc.
(see above)
White Balance Gamma, Gain, Offset etc. (see above)
Gamma Selection
2.8, 2.5, 2.2, 1.0,
RUNCO Enhance 1,
RUNCO Enhance 2 or ISF
Day
Blue Image On / Off
ICC Adjust NTSC / HDTV / PAL
R / G / B / Y / C / M
Intensity / Sat. / Hue
Store Settings
Memory 1, ISF Night or
ISF Day
Splash Screen Timer +5, +6, +7 ... +60 seconds
ISF Enable On / Off
Return to User OSD
Video
S-Video
Component1
Component2
RGB-HD
HDMI
Brightness 0 ... 60
Contrast 0 ... 32
Color 0 ... 64
Tint 0 ... 30
Sharpness -14 ... 0 ... +20
Filter 0, 1, 2 or 3
Color Temperature
0, 1 (5400 K), 2 (6500K), 3
(8500 K), 4 or 5 (Custom)
ICC Selection
Standard, NTSC, HDTV or
PAL
Store Image Settings Memory 1
Restore Image
Settings Memory 1, ISF Night or ISF
Day
Aspect Ratio
Anamorphic (16:9)
Standard (4:3)
Letterbox
Virtual Wide
Cinema
Virtual Cinema
(available only on CL-810
projectors equipped with
the CineWide option)
Installation
Language
English, French, Spanish,
German or Italian
Picture Orientation
Floor Front, Floor Rear,
Ceiling Front or Ceiling
Rear
Keystone Adjust -14, -13 ... 0 ... +13, +14
Background Color Blue or White
RS-232 Baud Rate 9600, 38400 or 115200
Blue Image On / Off
