Controls and Functions
8 Runco CL-810 Series Owner’s Operating Manual
PRE
L
IMINAR
Y
3. COMP 1 (RCA connectors)
Standard Definition (480i/576i) Component (YPrPb) input. This is the input for
component video from sources such as DVD players.
4. COMPOSITE VIDEO INPUT
Standard composite video input for connecting a VCR, laser disc player or other
composite video source.
5. S-VIDEO
A standard S-Video input for connecting a DVD player, satellite receiver or Super VHS
(S-VHS) VCR.
6. POWER INPUT (100 to 240 VAC)
Connect the CL-810 to power here.
7. MAIN POWER SWITCH
Disconnects or applies power to the CL-810.
8. RS-232 CONTROL PORT
A female, RJ-11 connector for interfacing with a PC or home theater
automation/control system.
9. 12-VOLT (250 mA) TRIGGER OUTPUT(3.5-mm, mini phono jack)
Connection for a 12-volt trigger-controlled device. This can be a retractable screen,
screen mask or the Runco CineWide with AutoScope system.
10. COMP 2 / RGB
Five, BNC connectors for connecting either RGB or component (YPbPr)
high-definition television signals. (The CL-810 automatically detects the signal format.)
For best results, do not run your DVD player in progressive mode.
Tip
