Figure 2-2 . cl-810 rear/bottom/side view, 2. cl-810 rear/bottom/side view, Pre l iminar y – Runco CL-810 CL-810 Ultra Cl-810 CineWide CL-810 / SDC-1 User Manual
Page 18
6
Runco CL-810 Series Owner’s Operating Manual
PRE
L
IMINAR
Y
6.
POWER/STANDBY LED
Indicates power status as follows:
• Orange when the projector is in standby mode
• Flashes orange for 45 seconds after the projector is turned on to indicate that the
lamp is warming up
• Green during normal operation
• Flashes green for 110 seconds after the projector is turned off to indicate that the
lamp is cooling down
7.
LAMP LED
Indicates lamp status as follows:
• Off during normal operation
• Red when the lamp has exceeded its usage life or developed a problem.
• Flashes red when the fans are not working or the lamp cover is open
8.
EXHAUST VENT
9.
FRONT IR SENSOR
Figure 2-2. CL-810 Rear/Bottom/Side View
1.
RUNCO LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.
2.
CABLE OPENING
Pass cables through this opening.
3.
CABLE ACCESS DOOR
Open to access connectors.
