Figure 3-4 . horizontal lens shift, 4. horizontal lens shift, Figure 3-4 – Runco CL-810 CL-810 Ultra Cl-810 CineWide CL-810 / SDC-1 User Manual

Page 31: Pre l iminar y

Runco CL-810 Series Owner’s Operating Manual

PRE

IMINAR

Figure 3-4. Horizontal Lens Shift

Screen Center

100% Width Lens Shift

(1.0 x W)

50% Width Lens Shift

(0.5 x W)

150% Width Lens Shift

(1.5 x W)

Screen Width (W)

Note:

This is a general example of lens shift. Lenses vary in their shift capabilities. No particular

lens is used in this example.
