Page 26: Pre l iminar y
14
Runco CL-810 Series Owner’s Operating Manual
PRE
L
IMINAR
Y
3.2
Quick Setup
Table 3-1 gives a quick overview of the CL-810 installation process. The sections
following this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step
Procedure
For Details, Refer to
page...
1
Choose a location for the projector
2
Install the CineWide (secondary anamorphic) lens (optional)
3
Mount the projector
4
If installing with an SDC-1, connect ONLY the SDC-1
output to the CL-810 and make all other connections to the
SDC-1; continue with Step 7
-- OR --
If installing without an SDC-1, connect signal sources to
the CL-810 and continue with Step 5
5
Connect external controller to RS-232 port (optional)
6
Connect other home theater components to 12-volt trigger
outputs (optional)
7
Apply power to the projector
8
Change the OSD Language (optional)
9
For rear-screen and/or ceiling-mount installations, select
the proper picture orientation
10
Lens adjustments: projected image size (zoom), position
(shift) and focus
11
Projector calibration: adjust the following
for each input,
starting with Component 1; save settings when finished:
• Aspect ratio
• Brightness
• Contrast
• Color level
• Tint
• Input position
Note
