Installation

Runco CL-810 Series Owner’s Operating Manual

27

PRE

L

IMINAR

Y

RS-232 Controller

Connection

Connect a PC or home theater control/automation system (if present) to the RS-232 port
on the CL-810; see Figure 3-11. Use a standard, 4-wire RJ-11 telephone cable, wired
straight-through.

For more information about using this connection, refer to

Serial Communications on

page 53.

Figure 3-11. RS-232 Control System Connection

S-VID /

S-VID
