Ricoh Caplio RX - Manual (Page 14)

14
1
4.
Close the battery/card cover and
slide it back into place.
• Please remove the rechargeable batteries
if you are not going to use the camera for a
long period of time.
• Use the battery charger BJ-2 (sold sepa-
rately) to recharge the battery.
• Store the removed battery in a dry cool
place.
Using the AC Adapter
If you have already used this camera, make
sure it is turned off before loading the AC
Adapter Battery.
Setting up the AC Adapter
1.
Make sure the camera's power is
off.
2.
Open the battery/card cover.
The cover slides open in two steps.
First slide the cover toward the face of
the camera, then lift it to expose the bat-
tery compartment.
3.
Insert the AC Adapter Battery.
Rechargeable battery charging time
(when using BJ-2)
DB-43 Approx. 220 min. (at room temperature)
Battery for use with
the AC Adapter
AC Adapter
