The pool’s chemistry must be balanced BEFORE activating the Aqua Logic’s sanitizing function. NOTE:
If the pool does not have new water, add metal remover and non-copper based algaecide to the pool, per
manufacturer’s instructions. This ensures a quick, troublefree transfer to the Aqua Logic system.
Salt
Salt Level
Use the chart below to determine how much salt in pounds or (Kgs) should be added to reach the recom-
mended levels. Use the equations on the following page (measurements are in feet/gallons and meters/
liters) if pool size is unknown.
The operating salt level is between 2700-3400 PPM (parts per million) with 3200 PPM being optimal.
Before adding any salt, test the salt level. This is especially important for retrofit installation to older pools
where all of the chlorine added to the pool over time is ending up as salt. If the level is low, determine the
number of gallons in the pool and add salt according to the chart below. A low salt level will reduce the
efficiency of the sanitization and result in low chlorine production. A high salt level can cause the Aqua
Logic to stop chlorinating. The salt in your pool/spa is constantly recycled and the loss of salt throughout
the swimming season should be minimal. This loss is due primarily to the addition of water because of
splashing, backwashing, or draining (because of rain). Salt is not lost due to evaporation.
