Controls and functions, 1 vx-2ix at a glance, Figure 2-1 . vx-2ix front/bottom/side view – Runco Video Xtreme VX-2ix User Manual
Page 17: Vx-2ix at a glance, 1. vx-2ix front/bottom/side view
Runco VX-2ix Owner’s Operating Manual
5
2.1
VX-2ix at a Glance
Figure 2-1 shows the key VX-2ix components.
Figure 2-1. VX-2ix Front/Bottom/Side View
1.
INTAKE VENT
2.
LENS
3.
RUNCO LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.
4.
EXHAUST VENT
5.
CABLE OPENINGS
Pass cables through these openings.
6.
IR SENSOR
2. Controls and Functions
2
3
4
5
5
1
6
