Roland V-Piano - Manual (Page 46)

46
Playing
1. In the tone screen, press the [FUNCTION] button to turn Function on.
The [FUNCTION] button will light.
2. Press the [F4 (UTILITY)] button to access the utility screen.
3. Use the [F3 ( ▲ )] or [F4 ( ▼ )] buttons to select “4. Pedal.”
fig.PdlAsgn01.eps
4. Press the [ENTER] button or the [F1 (ENTER)] button to access the pedal setting screen.
fig.PdlAsgn02.eps
5. Use the [F3 ( ▲ )] or [F4 ( ▼ )] button to select the pedal whose assignment you want to change.
fig.PdlAsgn03.eps
6. Turn the [VALUE] dial to select the function you want to assign.
If you select “OFF,” that pedal will not control anything.
Assigning a function to a pedal
Parameters Pedal
Center Pedal Assign Center piano pedal
Left Pedal Assign Left piano pedal
FC2 Assign Connected to the PEDAL FC2 jack
FC1 Assign Connected to the PEDAL FC1 jack
