Before You Start
Connecting the SP-404SX to Your Speakers
Make sure that the SP-404SX and your amplifi ed speakers (which we’ll simply call “speakers”) are powered off , and then make
connections as shown below .
Amplifi ed speakers
(sold separately)
Audio cables
(sold separately)
AC adaptor
LINE OUT jacks DC IN jack
LINE IN jacks
If you’re using headphones
(sold separately), connect them
here .
Place the AC adaptor so the side with
the indicator (see illustration) faces
upwards and the side with textual
information faces downwards .
The indicator will light when you plug
the AC adaptor into an AC outlet .
NOTE
To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power
on all devices before making any connections .
About Functional Ground Terminal
Depending on the circumstances of a particular setup, you may experience a discomforting sensation, or perceive that the
surface feels gritty to the touch when you touch this device, mics connected to it, or the metal portions of other objects .
This is due to an infi nitesimal electrical charge, which is absolutely harmless . However, if you are concerned about this,
connect the ground terminal (see fi gure) with an external ground . When the unit is grounded, a slight hum may occur,
depending on the particulars of your installation . If you are unsure of the connection method, contact the nearest Roland
Service Center, or an authorized Roland distributor, as listed on the “Information” page .
Unsuitable places for connection
• Water pipes (may result in shock or electrocution)
• Gas pipes (may result in fi re or explosion)
• Telephone-line ground or lightning rod (may be dangerous in the event of lightning)
