Roland VIMA JM-5 - Manual

1
Model: JM-5
Date: July 2011
Version: 1.00
MIDI Implementation
1. Received data
■ Channel Voice Messages
● Note off
● Note on
• Not received when Rx.NOTE MESSAGE= OFF. (Initial value is ON)
● Polyphonic Key Pressure
• The resulting effect is determined by System Exclusive messages. With
the initial settings, there will be no effect.
● Control Change
• The value specified by a Control Change message will not be reset even
by a ProgramChange, etc.
❍ Bank Select (Controller number 0, 32)
• Bank Select processing is suspended until a program change is received.
❍ Modulation (Controller number 1)
• Not received when Rx.MODULATION= OFF (Initial value is ON).
• The resulting effect is determined by System Exclusive messages. With
the initial settings, this is Pitch Modulation Depth.
❍ Portamento Time (Controller number 5)
❍ Data Entry (Controller number 6, 38)
❍ Volume (Controller number 7)
• Volume messages are used to adjust the volume balance of each Part.
• Not recevied when “Volume” RX Event is off.
❍ Pan (Controller number 10)
• Not received when “PanPot” RX Event is Off
❍ Expression (Controller number 11)
• Not received when "Expression" RX Event is Off.
❍ Hold 1 (Controller number 64)
• Not received when “Hold” RX Event is Off.
❍ Portamento (Controller number 65)
❍ Sostenuto (Controller number 66)
• Not received when “Sostenuto” RX Event is Off.
Status 2nd byte 3rd byte
8nH kkH ccH
9nH kkH 00H
n= MIDI channel number: 0H~FH (Ch.1~16)
kk= note number: 00H~7FH (0~127)
vv= note off velocity: 00H~7FH (0~127)
Status 2nd byte 3rd byte
9nH kkH vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
kk= note number: 00H~7FH (0~127)
vv= note on velocity: 01H~7FH (1~127)
Status 2nd byte 3rd byte
AnH kkH vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
kk= note number: 00H~7FH (0~127)
vv= key pressure: 00H~7FH (0~127)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n= MIDI channel number: 0H~FH (Ch.1~16)
mm= Bank number MSB: 00H~7FH
Initial value= 00H
ll= Bank number LSB: 00H~7FH
Status 2nd byte 3rd byte
BnH 01H vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= Modulation depth: 00H~7FH (0~127)
Status 2nd byte 3rd byte
BnH 05H vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= Portamento Time: 00H~7FH (0~127),
Initial value= 00H (0)
Status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n= MIDI channel number: 0H~FH (Ch.1~16)
mm, ll= the value of the parameter specified by RPN/NRPN
mm= MSB, ll= LSB
Status 2nd byte 3rd byte
BnH 07H vvH
n= MIDI channel number 0H~FH (Ch.1~16)
vv= Volume: 00H~7FH (0~127),
Initial value= 64H (100)
Status 2nd byte 3rd byte
BnH 0AH vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= pan: 00H~40H~7FH (Left~Center~Right),
Initial value= 40H (Center)
Status 2nd byte 3rd byte
BnH 0BH vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= Expression: 00H~7FH (0~127), Initial value= 7FH (127)
Status 2nd byte 3rd byte
BnH 40H vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= Control value: 00H~7FH (0~127)
Status 2nd byte 3rd byte
BnH 41H vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= Control value: 00H~7FH (0~127) 0~63= OFF, 64~127=
ON
Status 2nd byte 3rd byte
BnH 42H vvH
n= MIDI channel number: 0H~FH (Ch.1~16)
vv= Control value: 00H~7FH (0~127) 0~63= OFF, 64~127= ON
