SECTION 8: M ULTIBURNER C ONFIGURATION & I NSTALLATION
35 of 73
SECTION 8: MULTIBURNER CONFIGURATION & INSTALLATION
8.1 Initial Assembly
See Page 13, Section 6 for linear heater assembly
instructions.
See Page 25, Section 7 for u-tube heater assembly
instructions.
Check layout drawings for location of manifold pipe
installation.
Figure 24: Multiburner Damper Flange Installation
WARNING
Severe Injury Hazard
Secure burner to burner tube with bolts and
lockwashers.
Hang heater with materials with a minimum
working load of 75 lbs (33 kg).
Failure to follow these instructions can result
in death, injury or property damage.
WARNING
Cut/Pinch Hazard
Wear protective gear during installation,
operation and service.
Edges are sharp.
Failure to follow these instructions can result
in injury.
Fan Tube
Damper Flange
Assembly
Note:
Install in the
fully open position
Weld Spot
