B LACKHEAT ® HE I NSTALLATION O PERATION AND S ERVICE M ANUAL
14 of 73
Figure 18: Linear General Assembly Overview
Vent Cap or Bird Screen
Outside
W
all
Fan Tube
Reflector
Reflector End Cap
Reflector Support
Burner
Coupling
U-Clips
Burner Tube
Tube and Reflector Hanger
Tube Clamp
Package
Fan Assembly*
(F
or Single Heater)
Damper
Assembly
(Required for Multiburner)
*NO
TE:
Locate f
an a
w
ay
from w
et en
vironment
or use the IP54 protected f
an.
Fresh Air Supply
Internal Swirler
W
eld S
pot
