SECTION 6: LINEAR & DOUBLE LINEAR HEATER INSTALLATION
The figures in this section provide a general overview of
component placement in a Linear and Double Linear
system. The location of some components such as
supports and couplings is crucial for proper installation.
Assemble the heater components as shown on Page 14,
Figure 18.
For optional reflector configurations for linear heaters see
Page 6, Figure 3 through Page 7, Figure 9. Install
appropriate suspension hardware, beam clamps, chain or
rod at predetermined locations. Adjustments of chain
length will provide uniform pitch.
If any step is unclear, please contact Roberts-Gordon
LLC at +44 (0)121 506 7700.
6.1 Linear Standard Parts List
* PVC coating must be removed prior to installation.
** If an IP55 protected fan is required, this fan replaces
07260001, 07260002, or 07260003.
*** Some models may receive S-hooks (P/N 91907302)
or spring hooks (P/N 91903300), rather than bow
shackles.
WARNING
Cut/Pinch Hazard
Wear protective gear during installation,
operation and service.
Edges are sharp.
Failure to follow these instructions can result
in injury.
Part No.
Description
HE
15
ST
HE
20
ST
HE
25
ST
HE
30
ST
HE
35
ST
HE
40
ST
HE
45
ST
HE
50
ST
033XXXXX Burner Assembly (Input and Fuel Varies)
1
1
1
1
1
1
1
1
07260001
Fan Package XP 1
1
1
1
1
1
-
-
-
07260002
Fan Package XP 2 (optional)
-
-
-
-
-
-
-
-
07260003
Fan Package XP 3
-
-
-
-
-
1
1
1
07260051
Fan Package 1 IP55 (optional)**
1
1
1
1
1
-
-
-
07260052
Fan Package 2 IP55 (optional)**
-
-
-
-
-
-
-
-
07260053
Fan Package 3 IP55 (optional)**
-
-
-
-
-
1
1
1
03051100
Burner Tube, 100 mm x 3048 mm
1
1
1
1
1
1
1
1
91409408
Tube, 100 mm x 3048 mm
-
1
1
2
2
2
3
3
S5127W
Fan Tube, 100 mm x 3048 mm, with 3048 mm Swirler
-
1
1
1
1
1
1
1
S5134W
Fan Tube, 100 mm x 3048 mm, with 2134 mm Swirler
1
-
-
-
-
-
-
-
01329600
Standard Coupling Assembly
1
2
2
3
3
3
4
4
01329700
Coupling Lock
1
2
2
3
3
3
4
4
02750303
Reflector, Aluminium, 2439 mm
3
4
4
6
6
6
7
7
027503SS Reflector, Stainless Steel, 2439 mm (Optional)*
3
4
4
6
6
6
7
7
02750800
Reflector End Cap, Aluminium
2
2
2
2
2
2
2
2
027508SH Reflector End Cap, Stainless (Optional)*
2
2
2
2
2
2
2
2
03090100
Tube and Reflector Hanger
3
4
4
5
5
5
6
6
01318901
Tube Clamp Package (including Nut, Washer & Bolt)
1
1
1
1
1
1
1
1
91908004
Wire Form
2
3
3
5
5
5
6
6
94320812
Screw #8 x 3/4, (Goes with 03050000)
4
6
6
10
10
10
12
12
03050000
Reflector Support Strap
2
3
3
5
5
5
6
6
E0007576
Bow Shackle***
3
4
4
5
5
5
6
6
91107720
U-Clip Package (20 Pieces)
1
1
1
1
1
1
1
1
S7199K
Damper Flange Assembly (For use on Multiburner Systems)
1 Per Heater
