Operational Specifications

3.1.4 Power Supply Connector (J4)

Rev.1.00 June 1,2005

3-6

REJ11J0002-0100Z

3

3.1.4 Power Supply Connector (J4)

The M3A-HS60 includes a power supply connector for the board itself.

Figure3.1.5 shows a pin assignment of power supply connector.

Top view of the

Component side

Side view

Board edge

Board edge

2

1

2

1

J4

Figure3.1.5 Pin Arrangement of Power Supply Connector (J4)

Table3.1.5 lists pin assignments of power supply connector for the M3A-HS60.

Table3.1.5 Pin Assignments of Power Supply Connector (J4)

Pin

Signal Name

Pin

Signal Name

1 +5V

2 GND
