Base Module
855-900547-200 2-29
2.4.4.1. Details of Partition Status Display
The status information for each partition consists of the following items:
xx N sssssssssssssss cccccc
ttttttttttttttttttttttttttttttt
uuuuuuuuuuuuuuuuuuuuuuuuuuuuuuu
1 2 3 4
5
6
No. Item Description
(1) Numeral Represents the system No. Fixed to 00 for all other
models.
(2) Numeral (0-7) Denotes the partition number.
(3) Character string Represents partition states.
POWER OFF Indicates DC OFF state.
STOPPED Indicates DC ON, No Failure, and Halt state.
HW INITIALIZING Means that the iSP is initializing the HW. BIOS is still not
booted.
SW INITIALIZING Means that the system is being initialized by BIOS.
OS BOOTING Means that the OS is being booted (HP-UX only).
RUNNING Means that control is passed to EFI after system
initialization by BIOS is complete.
FAULT Means that the system is in Halt state due to failure.
SHUT DOWN Means that the ISP is shutting down the HW.
NOT CONFIGURED Means “Not Configured.”
(4) 6 digit hex number Represents the latest chassis code sent from the BIOS
or OS.
(5) Character string Four-digit error code provided by BIOS.
It is cleared when the system is booted next time, or
with the CS command.
(6) Character string Warning or error message provided by the SP, shown in
the same format as Activity logs. For long messages,
their tail part will be omitted.
It is cleared when the system is booted next time, or
with the CS command.
