Operation Procedure

855-900547-200 3-10

Shutdown Flowchart

Step

Operation

1

Enter “shutdown –h now” on the OS console.

2

Check that “Power down.” is displayed.

For details of the shutdown command, refer to the OS manual.

3

When multiple partitions have been selected, repeat steps 1 and 2 for all partitions.

4

Check that the following is displayed on the SP console:

**************************************************
* All DC power has been turned off. *
* You can turn off AC power. *
**************************************************

5

Check that the CPU cage fan in the main cabinet stops turning.

For the location of the cage fan, see Figure 1-2 in Section 1.1.

6

Turn off the console management PC.

7

Turn off the AC switches in the main cabinet.

AC SW1 and SW2 can be turned off in any order.

8

Turn off the AC power circuit breakers at the lower part of the rear of the main cabinet.

The AC power circuit breakers on POWER BAY#0 and POWER BAY#1 can be turned off in

any order.

9

When the expansion cabinet is used, turn off the AC switches in the cabinet.

AC SW1 and SW2 can be turn off in any order.

10

When the expansion cabinet is used, turn off the AC power circuit breakers at the lower part

of the rear of the cabinet. The AC power circuit breakers on POWER BAY#2 and POWER

BAY#3 can be turned off in any order.

11

Turn off the peripheral units excluded from power control via the main cabinet.

12

Turn off the distribution board.
