NETGEAR DG834GUV5 - Manual (Page 92)

DG834GUv5 Wireless Router with Built-in DSL Modem User Manual
v1.0, May 2009
7. The LAN IP address and Subnet mask that was configured on the Telkom VPN Lite Website
must also be entered.
8. Review the configuration details you have entered and click Finish if you are satisfied to
complete the VPN Lite setup:
Note: The IP address for each site configured must be different and fall within a different
IP Subnet range.Example: [email protected] can be 10.0.1.0/24, then the IP
subnet for [email protected] must be a different subnet, like 10.0.2.0/24. The IP
Address must correspond exactly to the one configured on theVPN Lite Webpage.
Figure 6-5
Note: After selecting Finish, you may need to connect to your router with the new LAN
IP address entered during configuring VPN Lite. Please wait until the progress bar
on the router menu page has completed before attempting to reconnect.
6-4
