46 CallPilot server installation
Step Action
1 Plug the power cords into all peripheral devices, including the
monitor, tape drive, and Ethernet switch or hub as applicable to
system setup.
2 Turn on all peripheral devices.
3 Plug the power cords into the CallPilot server.
Check that the status LEDs on the power supply are lit green.
4 Do one of the following:
• For the 1005r server, push the power switch on the front panel
to power on the server.
• For the 600r server, if the server does not start automatically
when you plug in the power cords, push the power switch on the
front panel to power on the server.
5 Check that the status LEDs on the power supply are blinking green.
6 Wait while the server configures Windows 2003.
After the server automatically restarts several times, the Windows
logon screen appears.
—End—
