9
PARTS GUIDE (A4.6Ci)
LED Zone ON/OFF Indicator
Zone Label Slots Removable Programming Cover
DB-9 Computer
Interface
Sensor for Capturing
IR Commands
Programming Controls
and Indicators
Connection for
Programming
Keypads
Zone All On/Page
Enable Switches
DB-9 Computer
Interface
Sensor for Capturing
IR Commands
Programming Controls
and Indicators
Figure 4 A4.6Ci Rear Panel
16V DC
Power Input
Keypad
Inputs
Flasher
Outputs
12V Control
Output
IR Input
Sync
Inputs
System
Expansion
DB25
Zone Audio
Output
Paging
Input
Audio Inputs
with Buffered
Cascade Outputs
Zone Audio
Outputs
Figure 2 A4.6Ci Front Panel with Programming Cover Figure 2 A4.6Ci Front Panel with Programming Cover
Figure 3 A4.6Ci Front Panel with Programming Cover Removed
