Niles Audio A4.6Ci - Manual (Page 103)

103
SPECIFICATIONS
A4.6Ci MultiZone Audio Preamplifier
Frequency Response: 12 Hz - 230 KHz, 3 dB, at 1Vrms output
Paging = -3dB > 200Hz - 4 KHz
Distortion: <0.005% THD, 1 KHz
Maximum Output: 6 Vrms before clipping
Overall Voltage Gain: 27 db
Maximum Input Level: 1 Vrms
Signal-to-Noise Ratio: >90 db at 1Vrms output
Crosstalk: >90 db at 1Vrms (between zones & channels)
Input Impedance: 10k ohms
paging =100k ohms
Input Sensitivity: 330 mv input for 1V out (with zero db control gain)
paging =10 mv input for 1V out
Maximum Hum: >90 db
Channel Balance: 20 hz -20 khz +/- 0.5 db
Tone Control Range: +/-14 db 100 hz
+/-14 db 15 khz
Power Requirements: 16V DC, 1.5a
Net Weight (w/xf): 10.65 lbs
Dimensions: 17" wide x 1.3/4" high x 12" deep
