ReadyNAS 2100 User Manual
5-16 Optimizing Performance and Maintaining the System
v1.1, June 2009
7. Select either the Expandable Volume (X-RAID2) or the Flexible Volume (Flex-RAID) radio
button, configure the options accordingly, and click Create Volume Now. The volume and
initialization process begins.
RAIDar shows that the system is initializing the volume.
The system powers down when the volume initialization completes.
8. Power the system on. It will perform diagnostics while it boots.
9. Click Rescan in RAIDar to connect to the system.
RAIDar will find the system and show that it is booting.
10. When RAIDar shows that the system is ready, click Setup to log in to FrontView and
configure the system.
Note: If no action is taken within 10 minutes, the system defaults to X-RAID2 with
10 GB reserved for snapshots.
Figure 5-20
Figure 5-21
