19
Getting Started
Installation
Analog RGB signals that can be input
The table below lists the different types of analog RGB signals that can be input.
If a signal which differs greatly from any of the types listed below is input, the picture image may not be displayed
correctly, or a black background may be displayed. At this time, “signal” will flash in the on-screen display for about 5
seconds.
Notes:
• Input signals, other than those listed with a
*
mark, will give you a beautiful, stable picture.
• The front D-SUB15P connector can accept RGB(H-V sync separate) and RGB(sync on green). However, it is
not guaranteed to display stable color when using RGB(sync on green).
• When used with an external video processor/scaler, it must have RGB(H-V sync separate) output.
Personal Computer Signals
DTV Format
Signals
Mode type
Signal data
No. of dots
(H x V)
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
VGA400 (70 Hz) 640 X 400 31.47 70.08 VGA400 70Hz
VGA480 (60 Hz) 640 X 480 31.47 59.94 VGA 60Hz
Macintosh 13˝ 640 X 480 35.00 66.67 MAC 13
VESA400 (85 Hz) 640 X 400 37.86 85.08 VESA 85Hz
VESA480 (72 Hz) 640 X 480 37.86 72.81 VGA 72Hz
VESA480 (75 Hz) 640 X 480 37.50 75.00 VGA 75Hz
VESA480 (85 Hz) 640 X 480 43.27 85.01 VGA 85Hz
SVGA (56 Hz) 800 X 600 35.16 56.25 SVGA 56Hz
SVGA (60 Hz) 800 X 600 37.88 60.32 SVGA 60Hz
SVGA (72 Hz) 800 X 600 48.08 72.19 SVGA 72Hz
SVGA (75 Hz) 800 X 600 46.88 75.00 SVGA 75Hz
SVGA (85 Hz) 800 X 600 53.67 85.06 SVGA 85Hz
Macintosh 16 ″ 832 X 624 49.73 74.55 MAC 16
* XGA (60 Hz) 1 024 X 768 48.36 60.00 XGA 60Hz
* XGA (70 Hz) 1 024 X 768 56.48 70.07 XGA 70Hz
* XGA (75 Hz) 1 024 X 768 60.02 75.03 XGA 75Hz
* Macintosh 19 ″ 1 024 X 768 60.24 74.93 MAC 19
* XGA (85 Hz) 1 024 X 768 68.68 85.00 XGA 85Hz
480 i 664 X 485 15.73 29.97 480 i
480 p 720 X 483 31.47 59.94 480 p
720 p 1 280 X 720 45.00 60.00 720 p
*1080 i 1 920 X 1 080 33.75 30.00 1080 i
Information menu
display
