10
For assistance, please call : 1-888-VIEW PTV(843-9788)
A
A
Open
Controls and Terminals on the projection display
< FRONT >
LAMP indicator
This indicator lights up when there
is a malfunction with the lamp unit.
(PP. 21, 60, 68)
TEMP indicator
This indicator lights up when
there is an abnormal
temperature in the unit.
(P. 68)
Remote Control Sensor
POWER button/
POWER indicator
(P. 21)
Lamp unit
(P. 60)
Speaker cover
Press the mark on
the center of the front
cover to open.
Volume up(+) / down(–) buttons
(P. 28)
Channel up / down buttons
(P. 29)
PC Input terminal
(P. 18) Input 3 terminals
(P. 15)
Location of Controls
Phones jack
Connect an earphone/headphones
(not supplied) to the Phones jack.
Speaker cover
Air filter
(P. 58)
