How to connect the COMPONENT VIDEO Input Terminals
Notes:
• Similar connections are available at the COMPONENT VIDEO INPUT 1, 2 Terminals.
• Select the desired COMPONENT VIDEO INPUT position by pressing the TV/VIDEO button. (P. 33)
• Component video signals that can be input are 480i, 480p, 720p, and 1080i.
Installation
Audio
OUT P B Y P R
DVD(Y/P B /P R ) OUT
L R
DVD Player
COMPONENT VIDEO
AUDIO
Because each Y, P B , and P R signal is input independently, the Component signal allows for more accurate color
reproduction.
The Component signal output terminal indication will differ according to the output device (Y, P
B / Cb, P R / Cr). Please
read the operating instructions included with the output device.
