1. ON
Use this button to turn the projector on.
2. OFF
Use this button to turn the projector off.
3. Source Selection Buttons (1-5):
Press to select a video source. By default, these buttons are assigned as
follows: 1 = HDMI 1; 2 = HDMI 2; 3 = Component 1; 4 = S-Video; 5 = Video.
However, you can assign each button to any source you wish.
4. Cursor Buttons ( , , , )
Use these buttons to select items or settings, adjust settings or switch display
patterns.
ENTER
Press to select a highlighted menu item or confirm a changed setting.
When no menu is present on-screen, press ENTER to access the motorized
lens focus control. Press ENTER again to access the motorized lens zoom
control. Press ENTER yet again to access the motorized lens shift control.
Use the and buttons to adjust focus, zoom or vertical lens position. Use
the and buttons to adjust horizontal lens position.
5. Aspect Ratio Selection Button
Press this button repeatedly to select one of the following aspect ratios:
16 : 9: For viewing 16:9 DVDs or HDTV programs in their native aspect ratio.
Letterbox: For viewing LaserDisc movies or non-anamorphic DVDs on a 16:9
screen.
4 : 3: Scales the input signal to fit 4:3 sources in the center of the screen.
4:3 Narrow: Scales the input signal to fit 4:3 sources in the center of the
screen when using an anamorphic lens.
Native: Displays source image in its native resolution without re-sizing or
overscan.
6. MENU
Press this button to show or hide the OSD controls.
7. Memory Preset Buttons (M1 / M2 / M3)
Press to recall settings for the current input from one of three memory
presets. By default, these buttons are assigned as follows: M1 = User
Memory 1; M2 = User Memory 2; 3 = ISF Night. However, you can assign each
button to any memory preset you wish.
