7
Specifications
PDP-427CMX
Power requirements ............ AC 100 V to 120 V, 50 Hz/60 Hz
(The power unit range is from AC100 V to 240 V (50 Hz/60 Hz))
In-rush ............................................................... less than 30 A
Power factor .................................................... more than 0.95
Consumption ......................... 285 W
(NOTE 2) (1.2 W in standby)
External dimensions (not including the handles and supplied stand)
........................... 1022 mm (W) × 610 mm (H) × 98 mm (D)
40-1/4 in. (W) × 24-1/32 in. (H) × 3-27/32 in. (D)
Weight (without attachment stand) ......... 30.5 kg (67.3 lbs.)
Dimensions of packaging
......................... 1177 mm (W) × 767 mm (H) × 354 mm (D)
46-11/32 in. (W) × 30-7/32 in. (H) × 13-31/32 in. (D)
Weight when packaged ................................. 38 kg (83.8 lbs.)
Operating Temperature .... 0 °C to 40 °C (32 °F to 104 °F)
(NOTE 3)
Operating Humidity .......................................... 20 % to 80 %
Operating atmospheric pressure .......... 800 hPa to 1114 hPa
Storage limitations (when installed)
Temperature .................. –20 °C to +60 °C (–4 °F to 140 °F)
Humidity ......................................................... 20 % to 90 %
Atmospheric pressure ......................... 700 hPa to 1114 hPa
Storage limitations (when in original package)
Temperature ................ –30 °C to +60 °C (–22 °F to 140 °F)
Humidity ......................................................... 20 % to 90 %
Atmospheric pressure ......................... 700 hPa to 1114 hPa
Stacking ............................................ Fewer than three tiers
Standard accessories
Power cord .............................................................................. 1
Ferrite core (for power cord) ................................................... 2
Ferrite core (for audio cables) ................................................. 3
Cable ties ................................................................................ 2
Remote control unit ................................................................ 1
AA battery ............................................................................... 2
Wiping cloth (for screen) ......................................................... 1
Speed clamp ........................................................................... 3
Operating instructions ............................................................. 1
Warranty ................................................................................. 1
Remote control unit holder ..................................................... 1
Display stand ........................................................................... 2
Washer .................................................................................... 2
Hexagon socket head screw (M8 x 40) ..................................
2
Specifications and external designs are subject to change without
notice.
(NOTE 1) The display is preset at the factory to 9600bps. This
setting can be changed using either the remote control
unit or a PC.
(NOTE 2) Allow for 320 W = 320 VA of consumption per unit.
(NOTE 3) The correct operating environmental temperature may
vary depending on the installation site (refer to
“Installation Site Requirements (pg. 20)”.
Light-emitting panel ..................... 42V type AC Plasma Panel
92.16 cm (W) × 51.53 cm (H) × 105.59 cm (diagonal)
Aspect ratio .................................................................... 16 : 9
Pixels ...................................................................... 1024
× 768
Pixel pitch ..................... 0.9 mm (H•RGB trio) × 0.671 mm (V)
Input/output terminals
Video-related
INPUT 1
Input Mini D-sub, 15-pin connector (female)
• RGB signal (for SYNC ON G)
RGB ............................... 0.7 Vp-p/75 Ω/no sync
HD/VS, VD ........ TTL level/positive and negative
polarity/2.2 k Ω
SYNC ON G ............ 1 Vp-p/75 Ω/negative sync.
*Microsoft Plug & Play (VESA DDC 1/2B) supported
Output Mini D-sub, 15-pin connector (female)
.................................. 75 Ω/with buffer
INPUT 2
Input DVI-D 24-pin connector
Digital RGB signal (DVI compliant TMDS signal)
*Microsoft Plug & Play (VESA DDC 2B) supported
Audio-related
Input AUDIO INPUT (for INPUT1)
Stero mini jack
L/R ...................... 500 mVrms/more than 10 k
Ω
AUDIO INPUT (for INPUT2)
Stero mini jack
L/R ...................... 500 mVrms/more than 10 k
Ω
Output AUDIO OUTPUT
Stero mini jack
L/R .......................... 500 mVrms/less than 5 k
Ω
SPEAKER
L/R ................... 6 Ω to 16 Ω/8 W + 8 W (at 6 Ω)
Control-related
RS-232C terminal: D-sub, 9-pin (male)
(NOTE 1)
Combination In/Out Terminal: Mini-DIN, 6-pin
