[507CMX : 427CMX] Ceiling Mount Unit: PDK-5012
7 When using Plasma Display PDP-427CMX
(Unit: mm)
R580
R510
45°
45°
4- φ13.5X22
129
98
47
1062
110
67
80
277
(493) 329
100
φ70
φ240.5
211
300 200
1022
758
980
496
(530)
300 610
φ60.5
This circle shows the path that the outermost
part of the Plasma Display follows when it is
rotated on a vertical axis after having been
titled sideways by 25°.
This circle shows the path that the outermost
part of the Plasma Display follows when it is
rotated on a vertical axis after having been titled
sideways by 25°.
Attachment
holes
(6 locations)
