116
Ceiling Mount Unit: PDK-5012
4.8 Ceiling Mount Unit: PDK-5012
4.8.1 Specifications
External dimensions ................. 1222 mm (W)
× 1168 mm (H) × 300 mm (D)
(48-1/8 in. (W) × 45-31/32 in. (H) × 11-13/16 in. (D))
(mounting hardware and Plasma Display )
1022 mm (W)
× 1062 mm (H) × 300 mm (D)
(40-1/4 in. (W) × 41-13/16 in. (H) × 11-13/16 in. (D))
(mounting hardware and Plasma Display )
Weight ....................................... 14.5 kg (32.0 lbs.) (mounting hardware only)
50.0 kg (110.2 lbs.) (mounting hardware and Plasma Display )
45.0 kg (99.2 lbs.) (mounting hardware and Plasma Display )
Adjustable range of angles ...... Horizontal to 25 degrees below horizontal, 45 degrees left/right
Material ...................................... Steel pipe for general structure (STKM-R), STK, SPHC
Finish .......................................... Semi-matte black paint (Original Pioneer color)
Package dimensions ................. 1035 mm (W) × 360 mm (H) × 540 mm (D)
(40-3/4 in. (W) × 14-3/16 in. (H) × 21-1/4 in. (D))
Package weight ......................... 21.5 kg (47.4 lbs.)
Layers of packing ...................... 10 layers
Components
PDP bracket ........................................................ × 1
Bolts M8 .............................................................. × 6
Special screws .................................................... × 4
Hole cover ........................................................... × 1
Stencil (printed on the wrapping
material that is inside) ......................................... × 1
Installer's contact information (Japan only) ......... × 1
Operating instructions .........................................
× 1
The appropriate types of screws and other mounting hardware will depend on the strength and composition of the
ceiling. Purchase them separately.
✩ Operating Temperature Restrictions
• Ambient Temperature: 0 °C to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations (*1, *2)
• Ambient temperature: 0 °C to 40 °C
• Other factors: Maintain sufficient clearance between the display and the wall (at least 300 mm)
✩ Operating temperature restrictions for when the speaker system (PDP-S53-LR, PDP-S56-LR) is attached.
• Ambient temperature: 0 °C to 40 °C
*1 For this installation, set the ‘FAN CONTROL’ to ‘MAX’ as shown in “5.4.3 Adjustment and Setting in the Integrator Mode 14)
Cooling Fan Control Setting” (pg. 235).
*2 When INPUT2 has been selected, use input compatible signal up to 1280x1024 (60 Hz) at ambient temperature condition of 0 °C
to 35 °C.
[507CMX : 427CMX]
