201
Menu Mode [Applicable only when a PDA-5003/PDA-5004 is installed]
10) DVI Setting
Choose the component type (either [PC] or [VIDEO]) that is connected to INPUT2.
Settable condition: INPUT2
Factory setting: PLUG/PLAY: PC
BLACK LEVEL: LOW
1 Select ‘SETUP’.
2 Place the cursor on ‘DVI SET UP’ then press the [SET]
button.
3 Place the cursor over ‘PLUG/PLAY’ and press the [ 2/3]
button to change the setting.
Each time a [ 2/3] button is pressed, the setting changes
as shown below.
* Applicable only when the video card is installed.
4 Place the cursor over ‘BLACK LEVEL’ then press the [ 2/3]
button to change the setting.
Each time the [ 2/3] button is pressed, the setting
changes as shown below.
Note
When ‘PLUG/PLAY’ is set to ‘VIDEO’ then ‘BLACK LEVEL’ is set to ‘HIGH’. However, there are devices that can
adjust BLACK LEVEL so confirm the setting on the device.
M E N U I N P U T 1
SET EXIT MENU
S C R E E N S E T U P O P T I O N
P O W E R M G T. : O F F
S I G N A L F O R M AT
P I C T U R E
D V I S E T U P
ENTER
Screen 2
Screen 3
3 PC
VIDEO* 2
2
3
SET SET EXIT MENU
DV I S E T U P
P L U G / P L AY
B L AC K L E V E L
: P C
: L OW
Screen 4
SET SET EXIT MENU
DV I S E T U P
P L U G / P L AY
B L AC K L E V E L
: P C
: L OW
3
3 HIGH (16 to 235) 2
2 LOW (0 to 255)
