122
4.9 Mobile Cart: PDK-5014
4.9.1 Specifications
External dimensions ................. 1 1222 mm (W)
× 1718 mm (H) × 710 mm (D)
(48-1/8 in. (W) × 67-5/8 in. (H) × 27-15/16 in. (D))
(when using the Plasma Display )
1 1022 mm (W) × 1655 mm (H) × 710 mm (D)
(40-1/4 in. (W) × 65-5/32 in. (H) × 27-15/16 in. (D))
(when using the Plasma Display )
2 1222 mm (W) × 1718 mm (H) × 730 mm (D)
(48-1/8 in. (W) × 67-5/8 in. (H) × 28-3/4 in. (D))
(when using the Plasma Display )
2 1022 mm (W) × 1655 mm (H) × 730 mm (D)
(40-1/4 in. (W) × 65-5/32 in. (H) × 28-3/4 in. (D))
(when using the Plasma Display )
Note) 1 : External dimensions of Serial No. 1 to 510 of PDK-5014
2 : External dimensions of Serial No. 511 and higher of PDK-5014
Weight ....................................... 43.0 kg (94.8 lbs.) (stand only)
78.5 kg (173.1 lbs.) (stand and Plasma Display )
73.5 kg (162 lbs.) (stand and Plasma Display )
Materials .................................... STKM (steel pipe) SPCC and SS41
Finish .......................................... Melamine baking finish (silver metallic)
Dimensions of packaging ......... 1465 mm (W) × 200 mm (H) × 790 mm (D)
(57-11/16 in. (W) × 7-7/8 in. (H) × 31-3/32 in. (D))
(bracket, display stand section)
810 mm (W)
× 295 mm (H) × 810 mm (D)
(31-7/8 in. (W) × 11-5/8 in. (H) × 31-7/8 in. (D))
(stand shelf, leg section)
Package weight ......................... 38 kg (83.8 lbs.) (bracket, display stand section)
21 kg (46.3 lbs.) (stand shelf, leg section)
Layers of packing ...................... 10 layers
Components
Display stand ....................................................... × 1
Rear cover ...........................................................
× 1
Leg base .............................................................. × 1
Bracket ................................................................ × 1
Stand shelf ..........................................................
× 1
Hexagonal bored bolts (M8 × 20 mm) ............... × 10
Hexagonal bored bolts (M8 × 60 mm) ................. × 4
Hexagonal wrench .............................................. × 1
Washers .............................................................. × 4
Plate spring washers ...........................................
× 4
Mobile Cart: PDK-5014
✩ Operating Temperature Restrictions
• Ambient Temperature: 0 °C to 40 °C
✩ Operating temperature restrictions for when the speaker system (PDP-S53-LR, PDP-S56-LR) is attached.
• Ambient temperature: 0 °C to 40 °C
[507CMX : 427CMX]
