A. Command Line Interface
A-22 May 2001 6371-A2-GB20-20
show spanning-tree
Minimum Access Level: Operator
Command Mode: Standard
Displays the spanning-tree topology for the router.
Sample show spanning-tree display:
Spanning tree protocol – enabled
Bridge ID – priority 120, address 00:00:0d:00:00:00
Topology change detected/received – false
Timers (seconds): hello 2, max age 20, forward delay 15,
topology change 35, hold 1, aging 300
Root ID – priority 120, address 00:00:0d:00:00:00
Root path cost – 0
Root port ID – priority 128, number 0
Port eth1 ID – priority 128, number 1
Port eth1 state – disabled *
Port eth1 designated bridge – priority 120,
address 00:00:0d:00:00:00
Port dsl1 ID – priority 128, number 2
Port dsl1 state – disabled *
Port dsl1 designated bridge – priority 120,
address 00:00:0d:00:00:00
* Possible values for Port eth1 state and Port eth1 state are disabled, learning,
listening, forwarding, or blocked.
