Creating New Nodes
User’s Guide
69
Next Nodes
Next node specifies the next operation to go to when the modify function suc-
ceeds or fails.
Math Nodes
Math nodes perform basic mathematical operations on the contents of a file or
register.
Figure 45. Math Node Properties Dialog
Reverse Reverses the order of data in the specified register. For example, if the
register value were
123456 , this option would reverse the order of
characters in the string to 654321 .
Delete Erases the data from the specified register, field or file.
Clear 8th Bit Ensures that specified data is in seven-bit ASCII format. If the data is
stored in eight bits, this options clears the eighth bit.
For example, when you are working with a database file that originated
on the PC, this strips the 8th bit prior to uploading collected data to the
PC.
