Using XFER32
User’s Guide
93
•
•
•
The settings in these dialogs can be modified or customized to meet your com-
munications requirements.
General Tab
The
General
tab is the first tab displayed on the
XFER32 Setup
dialog box. Use
this section to modify the PDT’s
Connection
,
Baud Rate
,
Flow Control
,
Proto-
col
(
ACK/NAK is the only protocol used by the PT40), and
Maximum Errors
.
Window Size
and
Crash Recovery
are not supported by the PT40.
Figure 65. General Tab
Connection
Enter the
Connection
port for file transfers. Select from the list of
detected serial ports or modems.
Baud Rate
Select a
Baud Rate
for serial communications
from the pull-down list. The default value for
XFER32 is
19200
. The default value for the
PT40 is
9600
.
Note: The PT40 supports only baud rates
up to
38400
.
