Chapter 2 RFID PGL Commands
46
be in dynamic format. For dynamic
format, enter LOCK, where DFn is
the dynamic field defined in EXECUTE
mode.
format is the optional parameter to
specify the format for the passcode data.
Enter B for binary,
D for decimal, and H for hexadecimal.
The default is decimal if
format is not
specified.
mem bank Specifies which tag logical memory area
that this command will be applied. If
omitted, it defaults to the EPC memory
area. Other areas include Identification,
User Data, Access area, and Kill area.
Enter one of the following values:
‘EPC’ – EPC 12 bytes data area (default)
‘TID’ – Tag identification 8 bytes area
‘USR’ – User 32 bytes area
‘ACS’ – 4 bytes of access code area.
‘KIL’ – 4 bytes of kill code area
Bit Field A line description of a bit field; must have
one of the following syntax formats:
length;DFn;format
length A decimal number
specifying the bit length of
a field within a tag. The
maximum length is 64 bits
for binary or decimal
format. For hexadecimal
format, the bit length can
be up to the maximum bit
length specified for the
corresponding memory
bank.
DF n Indicate dynamic data
field to store the read
result. Replace
n with a
number ranging from 1 to
512 to identify the field
