Worksheets
B-2 7510-A2-GB20-10 November 1997
Network Interface
Configuration Option Settings Default in [Bold]
Network-initiated DSU Loopback (64K CC) [Enable], Disable
Data Scrambling (64K CC) Enable, [Disable]
V.54 Initiated DSU Loopback Enable, [Disable]
Data Port
Configuration Option Settings Default in [Bold]
Invert Transmit Clock Enable, [Disable]
Port (DTE) Initiated Loopbacks [Disable], Local, Remote, Both
Bilateral Loopback Enable, [Disable]
Carrier Control by RTS [Constant], Switched
CTS Control [Standard], Follow RTS, Forced On,
Circuit Assurance
RLSD Control [Standard], Forced On
DSR Control [Standard], Forced On, On During Test
Monitor DTR [Enable], Disable
Terminal Port
Configuration Option Settings Default in [Bold]
Monitor DTR [Enable], Disable
Inactivity Timeout Enable, [Disable]
Disconnect Time(minutes) range 1 – 60 [5]
