C. Traps and MIBs
C-20 March 2002 6300-A2-GB20-00
DSL Endpoint MIB
This DSL Endpoint MIB, pdn_DslEndpoint.mib, facilitates configuration of DSL
multirate products and is fully supported. Objects are clarified in
Table C-12, DSL
Endpoint Configuration Group Objects Table . The groups in this MIB are:
T IP Routing Group – This table is an extension of the ipCidrRoute table (see
IP CIDR Route Group (RFC 2096) on page C-9).
T IP Multicast Group
T IP Processing Group
T Console Group
SYSLOG MIB
System Log MIB (SYSLOG), pdn_syslog.mib, is fully supported.
Interface Configuration MIB
The Interface Configuration MIB, pdn_IfExtConfig.mib, is used to configure
interface-related objects and is fully supported. One object is clarified below:
T pdn_IfExtConfigIPRoutedPDUs (pdnIfExtConfigEntry 1) – You can configure
the IP-routed PDUs in the LLC SNAP encapsulation or VC-based
Multiplexing encapsulation (RFC1483) in the upstream direction. If neither is
configured, the value none is used.
Table C-12. DSL Endpoint Configuration Group Objects Table
Object Description Setting/Contents
ipCidrRouteUpstreamNextHop
(IpCidrRouteXEntry 1)
Corresponds to the upstream Next
Hop Router address.
If the DSL interface is numbered,
each upstream Next Hop Router
address must be in a subnet
defined by a DSL interface
IP address and subnet mask.
T Ethernet Interface IP address.
T 0.0.0.0 – No upstream next hop is
identified.
ipCidrRouteDownstreamValid
(IpCidrRouteXEntry 2)
If false, the row containing it is not
valid for downstream routing. T true
T false
ipCidrClearAllRoutes
(IpCidrRouteX 2)
If set to clear, all IP routes are
removed from the routing table. T noOp
T clear
ipCidrRouterID
(IpCidrRouteX 3)
Specifies the router ID (primary
IP address). Must be equal to a nonzero value for the
interface IP address.
pdnlpMulticastEnable
(pdnRouterConfiguration 1)
Enables or disables forwarding of
IP multicast packets. T enable
T disable
pdnlpProcessingEnable
(pdnRouterConfiguration 2)
Enables or disables service
domain processing of IP packets. This setting is retained across power
cycles.
pdnConsoleEnabled
(pdnRouterConfiguration 7)
Enables or disables the console
port. T true(1) – Enable.
T false(2) – Disable.
