3–25 Configuring the Printer
Host Interface: Centronics
Host
Interface
Data Bit 8 PI Ignored Data
Polarity
Resp.
Polarity
Busy On
Strobe
Latch On
Data
Prime Signal TOF Action Buffer Size
In K
PE Line
Function
Enable*
Disable
Enable*
Disable
Standard*
Inverted
Enable
Disable*
Leading*
Trailing
Reset*
Do Nothing
1 to 128
64*
PE= PE
PE=TOF sig
* = Factory Default
1 = If Installed
Enable*
Disable*
Enable*
Disable
IEEE 1284 Centronics Dataproducts Serial Autoswitching Coax Twinax Ethernet 1
Available only
in CT option
Available only
in CT option
Figure 3–7. Host Interface Menu: Centronics
Data Bit 8
Enable: Allows access to the extended ASCII character set.
Disable: The printer interprets bit 8 of each incoming data character as a zero,
regardless of its actual setting.
PI Ignored
The PI (Paper Instruction) signal controls vertical paper motion. It is dependent
on your host computer.
Enable: Ignores the PI signal and treats the data as characters or control codes.
Disable: Causes the printer to interpret the eight data lines as VFU commands
when the PI signal is true.
