Local Dial-In Off-Site Call Center
Branch
Offices
Home
Offices
Remote
Office
Headquarters
VoIP/data, tagged and prioritized
traffic, VPN IPSec encrypted, free
and secure inter-site calls
VoIP/data, tagged
and prioritized traf-
fic. Optionally VPN
IPSec encrypted.
Secure Tunnel for Voice-over-VPN & Data*
Secure Tunnel for
Voice-over-VPN & Data*
Internet
Corporate
LAN
Call Center
IP Network
IP Network
TI/E1/PRI FXS
FXS
FXS
FXO
FXS FXO/BRI
FXS or
FXO
Corporate
LAN
Corporate
LAN
PBX
Local PSTN Breakout
Local PSTN Breakout PSTN Access
PBX
SN4520 Up to 8 FXS ports, optional PSTN breakout, IP access routing
SN4830 Up to 8 FXS ports, optional PSTN breakout, IP access routing, 1 WAN
Recommended Products
Local Dial-in
SN4960
For T1/E1/PRI VoIP
SN4900 For analog dial-in—FXO
Off-site Call Center
SN4960
For T1/E1/PRI call center connection
SN4900 For analog call center connection—FXS
Recommended Products
SmartNode
SmartNode
SmartNode
SmartNode
SmartNode
SmartNode
SN4960/SN2400 Headquarters, for T1/E1/PRI PBX connection
SN4630
Headquarters, for BRI PBX connection
SN4520 Remote office, up to 8 analog line extensions
Recommended Products
See page 29
See page 28
See page 28
See page 30
See page 24 See page 26
* Optional license sold separately
