42 www.pridemobility.com Jazzy 1170XL
V I I . O P E R A T I O N
Figure 31. Europa Master Remote Keypad
Keypad
The keypad is located directly in front of the joy-
stick. It contains keys that you will use to control
your power chair. See figure 31.
On/Off Key
The on/off key toggles the system power on and
off.
WARNING! Unless faced with an
emergency situation, do not use
the on/off key to stop the chair.
This will cause the power chair
to stop abruptly.
WARNING! Always turn the power
off when you are stationary to
prevent unexpected movement.
NOTE: If the joystick is not in the neutral (cen-
ter) position when you turn on the power, you
may cause a fault in the system. See “Out Of
Neutral At Power Up.”
System Status Light
The system status light is normally on when the
system is powered up, and off when the system is
powered down. It will also flash trouble codes when the system detects a fault. See “Trouble Codes.”
Magnetic Locking Area
Your power chair is equipped with a feature that enables you to “lockout” unauthorized users. For this
function, you will need the magnetic key supplied with your power chair. If you lose this key, contact your
authorized Pride Provider.
To enable the lockout system:
1. Hold the magnetic key on or near the key symbol. The system will beep and automatically turn off.
NOTE: None of the remote lights should be lit.
2. Press the on/off key to turn on the power chair. The key symbol will flash, but you will not be able to
drive your power chair. This means that it is still locked.
3. Hold the magnetic key on or near the key symbol again to unlock the system. When the key symbol
stops flashing, you may turn on the power chair.
NOTE: If you turn on the power chair while it is locked and don’t unlock it after one minute, the power
chair will automatically turn off itself.
