Jazzy 1170XL
I I I . Y O U R P O W E R C H A I R
AMMETER
CONTROLLER CONNECTOR
(VSI SHOWN)
CHARGER INHIBIT CONNECTOR
(VSI ONLY)
CHARGER POWER CORD
ELECTRONICS TRAY
Figure 6. Jazzy 1170XL Power Base (Shroud Removed)
Figure 7. Jazzy 1170XL Electronics Tray
MANUAL FREEWHEEL LEVER
MAIN CIRCUIT
BREAKER
BATTERIES
MOTOR/BRAKE ASSEMBLY
FRONT TRAPEZE BAR
FRONT SEAT TOWER
REAR TRAPEZE BAR
REAR SEAT TOWER
