Jazzy 1170XL www.pridemobility.com 35
V I I . O P E R A T I O N
Charger Inhibit Connector
This connects the VSI to the onboard battery charger. This connection provides an inhibit that disables the
VSI when the battery charger is on. The charger inhibit connector is coded with colored dots. The dots are
positioned so that you align the flat side of the male connector with the flat side of the female connector
before making the connection.
WARNING! Failure to properly align the connectors can result in damage to the VSI, the
charger, and the connectors.
Thermal Rollback
The VSI controller is equipped with a thermal rollback circuit. The circuit monitors the temperature of the
controller, which roughly translates to motor temperature. In the event that the VSI controller becomes
excessively hot (above 140° F), motor current (amperage) is reduced. For every degree above 140° F, the
motor current limit is reduced by .55 amps until the VSI controller reaches 158° F, at which time the current
output is reduced to zero. This reduces your power chair’s “power,” which could also reduce your power
chair’s speed, and allows the electrical components and motors to cool down. When the temperature re-
turns to a safe level, your power chair resumes its normal operation.
VSI Error Codes
The VSI controller is designed with the user’s safety as the prime consideration. It incorporates many sophis-
ticated self-test features which search for potential problems at a rate of 100 times per second. If the VSI
detects a problem either in its own circuits or in the power chair’s electrical system, it may decide to stop the
power chair, depending on the severity of the problem. The VSI is designed to maximize the user’s safety
under all normal conditions. The table below identifies the individual error codes. Error codes are displayed
as a rapid flashing of the lights. If you get one of these error codes, contact your authorized Pride Provider.
FLASHING LIGHTS DIAGNOSIS AND SOLUTION
1 The batteries need charging or there is a bad connection to the battery. Check the
connections to the batteries. If the connections are good, try charging the batteries.
2 The left motor has a bad connection. Check the left motor connection.
3 The left motor has a short circuit to a battery connection. Contact your authorized
Pride Provider.
4The right motor has a bad connection. Check right motor connection.
5
The right motor has a short circuit to a battery connection. Contact your authorized
Pride Provider.
6 The power chair is being inhibited by the battery charger. Unplug the battery charger.
7 A joystick fault is indicated. Make sure that the joystick is in the neutral (center)
position before turning on the controller.
8 A controller system fault is indicated. Make sure that all connections are secure.
9 The parking brakes have a bad connection. Check the parking brake and motor
connections. Make sure the controller connections are secure.
10 An excessive voltage has been applied to the controller. This is usually caused by
a poor battery connection. Check the battery connections.
