Case 3: Voice communication via IP PBX server – IPX-2000
Device configurations on the VIP-321:
STEP 1:
Log in IPX-2000 and create two testing accounts/password: 100 / 123 (for ATA A), and 200 /
123 (for VIP-321 B) for the voice calls.
STEP 2:
Please log in VIP-321 via web browser, browse to the SIP settings menu and select the
Service Domain Settings menu. In the setting page, please insert the account/password
information obtained from your service provider (in this sample, we’re using PLANET
IPX-2000 as the PBX server for SIP account, call authentications), and then the sample
configuration screen is shown below:
„ VIP-321 A IP Address: 172.16.0.1
Line Number: 100
„ VIP-321 B IP Address: 172.16.0.2
Line Number: 200
Registration /
Authentication
Registration /
Authentication
IPX-2000 LAN IP Address: 172.16.0.200
