Paradise P300 User Manual

Page 200

Cat'

Message

First

Direction

Instr'

Body

Partner

Function

Mnemonic

Avail'

Code

Length (optional)

P300H

P300 Series Modem Installation and Operating Handbook

Page 200

CommsPing

V1.37

to unit

(ack)

Query

Used to test comms integrity, and general acknowledge for many commands
which do not directly request a response

Ack (original)

V0.61

from unit

General Ack to

Acknowledge

many messages

Ack (extended)

V0.61

from unit

Note: Instruction codes used for SA-bus messages are as specified above + 30H. SA-bus instructions 70-7F are not used

* Note on `First Available` column
Items marked have been available since the version specified, but only in specific builds, there are different builds of the code as follows:

Build Name

Filename

Marked message available ?

Comments

P440 build

P440Vxxx

Build applicable only to Q460 board (ID_Dig=0) with Xilinx IFU (ID_IFU=0) and 4M code storage (Boot_Code will be V1.x for 4M)

P460 build

P460Vxxx

Build applicable only to Q460 board (ID_Dig=0) with ASIC IFU (ID_IFU=1 or 2) and 4M code storage (Boot_Code will be V1.x for 4M)

P480 build

P480Vxxx

Yes

Build applicable to all Q480 boards (ID_Dig=1, all of which have 8M code storage) with any IFU, OR a Q460 board (ID_Dig=0) modified to have
8M code storage (Boot_Code will be V2.x for 8M) fitted with any IFU

P300 build

P300vxxx

Yes

Build applicable to all P300's
