7.2
PD520 Dimensions
Figure 7-1 shows the PD520 dimensions (all dimensions are in inches).
Figure 7-1. PD520 Dimensions
49.84
23.62
W
all Mount Screw
6 x M8 T
ap
45.35
4.51
11
.22
7.87
7.87
5.55
25.51
3.72
30.00
33.72
