Planar PD520 Owner’s Operating Manual 7
PREL
IMINA
RY
1. INPUT2 Audio Input
2. INPUT2 Composite Video Input
Standard composite video input for connecting a VCR, camcorder, laser
disc player or other composite video source.
3. INPUT2 S-Video Input
Standard S-Video input for connecting a DVD player, satellite receiver or
Super VHS (S-VHS) VCR.
4. Headphone Jack
5. Main Power Switch
6. Power Input (100 to 240 VAC)
Connect the PD520 to power here.
7. RGB
A 15-pin VGA connection to a personal computer. The PD520 automatically
detects the signal resolution.
8. HDMI1/Computer Input (Digital)
9. HDMI2/Computer Input (Digital)
Two, HDCP-compliant digital video inputs for connecting a DVD player,
personal computer or HD tuner with a DVI or HDMI output.
10. PC Audio Input
Connect the audio output from a personal computer here.
11. INPUT3 Component Video (RCA connectors)
Standard-definition (480i/p, 576i/p) or high-definition (720p, 1080i/p), YPrPb
component input. Connect a DVD player or other component video source
to this input.
12. INPUT3 Composite Video Input
13. INPUT3 Audio Input
Connect the audio output from your Input 3 source here.
14. INPUT4 Component Video (RCA connectors)
Standard-definition (480i/p, 576i/p) or high-definition (720p, 1080i/p), YPrPb
component input. Connect a DVD player or other component video source
to this input.
15. INPUT4 Composite Video Input
16. INPUT4 Audio Input
Connect the audio output from your Input 4 source here.
17. INPUT1 Composite Video Input
18. INPUT1 Audio Input
Connect the audio output from your Input 1 source here.
19. INPUT1 S-Video Input
20. Monitor-OUT (Composite Video)
21. Monitor-OUT (Audio)
For best results, do not run your DVD player in progressive
mode. Tip
