14 Planar PD520 Owner’s Operating Manual
PREL
IMINA
RY
3.2
Quick Setup
Table 3-1 gives a quick overview of the PD520 installation process. The sections
following this one provide detailed instructions.
Installation should be performed by a qualified custom
video installation specialist.
Table 3-1. Installation Overview
Step Procedure
For Details, refer to
page...
1 Mount the PD520 on a wall (optional) 15
2 Connect signal sources to the PD520 16
3 Connect external controller to RS-232 port (optional) 22
4 Apply power to the PD520 23
5 Change the OSD language 23
6 If using the PD520 with a PC, adjust PC display
properties 24
7 Display calibration: adjust the following for each
input; save settings when finished:
• Brightness
• Contrast
• Color level
• Tint
• Input position
27 through 36
Note
