7. CONTRAST (+ / -)
Use these buttons to adjust the contrast.
8. Sound Control Buttons
VOL - / VOL +
Use these buttons to adjust sound volume.
MUTE
Press this button to mute the audio output to the speakers and headphones.
9. Source Selection Buttons
INPUT 1 / INPUT 2 / INPUT 3 / INPUT 4
Use these buttons to select Input 1, Input 2, Input 3 or Input 4.
HDMI 1 / HDMI 2
Use these buttons to select a Digital Video input (HDMI 1 or HDMI 2).
PC
Press this button to switch to the PC input.
AUTO
Press this button to have the PD520 search all inputs for an input signal, in this
order: Input 1, Input 2, Input 3, Input 4, PC, HDMI 1, HDMI 2. The PD520
displays the first one it finds. Press AUTO repeatedly to search for an active
signal on the other inputs.
10. Arrow Buttons ( , , , )
Use these buttons to select items or adjust settings.
ENTER
Press to select a highlighted menu item or confirm a changed setting.
11. MENU
Press this button to access the on-screen display (OSD) controls, or to exit
the current menu and return to the previous one.
12. EXIT
Press this button to hide the OSD controls.
13. INFO
Press this button to view input signal information (source and resolution).
Input 1 and Input 2 have both S-Video and composite
video connectors. Input 3 and Input 4 have both
component and composite video connectors.
To specify which connection type you are using – or to
switch from one to the other if equipment is connected to
both – use the Input Selection menu under Setup (refer to
Note
